GuardShield™ Safe 2 Safety Light Curtain User Manual
25
R
Original instructions
Corner Mirror for Multi-Sided Guarding
Specially constructed glass mirrors for 2- and 3-sided safeguarding applications.
Note: Each mirror reduces maximum scan range by 10% per mirror. Each corner mirror supplied with two end-cap mounting brackets.
Mounting Stand
GuardShield Safe 2 Light
Protected Height
[mm (in.)]
Narrow Mirror Short-
Range 0…4 m
Mirror Height
[mm (in.)]
Cat. No.
Wide Mirror Long-Range
4…15 m
Mirror Height
[mm (in.)]
Cat. No.
120/240 (4.7/9.4)
300 (11.8)
440L-AM0750300
300 (11.8)
440L-AM1250300
360 (14.2)
450 (17.7)
440L-AM0750450
450 (17.7)
440L-AM1250450
480 (19)
600 (23.6)
440L-AM0750600
600 (23.6)
440L-AM1250600
600 (24)
750 (29.5)
440L-AM0750750
750 (29.5)
440L-AM1250750
720/840 (28/33)
900 (35.4)
440L-AM0750900
900 (35.4)
440L-AM1250900
960 (38)
1050 (41.3)
440L-AM0751050
1050 (41.3)
440L-AM1251050
1080 (43)
1200 (47.2)
440L-AM0751200
1200 (47.2)
440L-AM1251200
1200 (47)
1350 (53.1)
440L-AM0751350
1350 (53.1)
440L-AM1251350
1320/1440 (52/57)
1500 (59.1)
440L-AM0751500
1500 (59.1)
440L-AM1251500
1560 (61)
1650 (65)
440L-AM0751650
1650 (65)
440L-AM1251650
1680 (66)
1800 (70.9)
440L-AM0751800
1800 (70.9)
440L-AM1251800
1800/1920
None Available
None Available
1828.8
(72)
63.5 (2.5)
25.4
(1.0)
12.7 (0.5) Dia. 4X
6.35
(0.25)
6.35
(0.25)
76.2
(3.0)
19.05 (0.75)
11.1 (7/16) Dia.
25.4
(1.0)
76.2
(3.0)
63.5
(2.5)
304.8
(12)
M10 x 1.5 mm
Class 6g thru 4 pl
381.0 (15)
60
(2.36)
150
(5.9)
12
(0.47)
2015
(79.3)
2000
(78.7)
240
(9.45)
60
(2.36)
Base Plate
440L-AMSTD
445L-AMSTD2M
