Control wiring – Rockwell Automation 150 SMC Flex Quick Start User Manual
Page 7

SMC™ Flex Quick Start 7
Control Wiring
Refer to the product nameplate for additional details. Depending on the specific application, additional control
circuit transformer VA capacity may be required.
Controllers rated 5…480 A
Control power is connected to the product through terminals 11 and 12.
Controllers rated 625…1250 A
Control power is connected to the product through terminal block CP1, at terminals 1 and 4.
Conductor Range
0.75…2.5 mm
2
(18…14 AWG)
Torque
0.6 N•m (5 lb•in)
Maximum Number of Wires per Terminal
2
AC Control Voltage Input
100…240V AC or 24V AC (+10/-15%)
Supply Type
1-phase, 50/60 Hz
24V AC Power Requirement
130VA
100…240V AC Power Requirement
75VA
DC Control Voltage Input
24V DC (+10/-15%)
Inrush Current
5 A
Inrush Time
250 ms
Transient Watts
60 W
Transient Time
500 ms
Staedy State Watts
24 W
Recommended Supply
1606-XLP50E
Fan Power Input (AC only)
separately wired
F5…F135
20VA
F201…F251
40VA
F317…F480
60VA
Conductor Range
0.75…2.5 mm
2
(18…14 AWG)
Torque
0.6 N•m (5 lb•in)
Maximum Number of Wires per Terminal
2
Control Voltage Input
110/120V AC or 230/240V AC, (+10/-15%)
Supply Type
1-phase, 50/60 Hz
Control Power Input
800VA (includes controller, bypass, and fans)
