38 Rockwell Automation Publication 750-UM003B-EN-P - July 2013
Appendix A Specifications and Certifications
Environmental Specifications This table provides environmental specifications.
Category Specification
Surrounding air temperature, max
IP20, NEMA/UL Open Type
IP00, NEMA/UL Open Type
IP20, NEMA/UL Type 1 (with hood)
IP20, NEMA/UL Type 1 (with label)
IP20, NEMA/UL Type 1 (MCC cabinet)
Flange mount –
Front
IP20, NEMA/UL Open Type
IP00, NEMA/UL Open Type
Back/Heat sink
IP66, NEMA/UL Type 4X
Standalone/Wall mount –
IP54, NEMA/UL Type 12
0…50 °C (32…122 °F)
0…50 °C (32…122 °F)
0…40 °C (32…104 °F)
0…40 °C (32…104 °F)
0…40 °C (32…104 °F)
0…50 °C (32…122 °F)
0…50 °C (32…122 °F)
0…40 °C (32…104 °F)
0…40 °C (32…104 °F)
Frame 1…5, all ratings
Frame 6…7, all ratings
Frame 1…5, all ratings
Frame 6…7, all ratings
Frame 8…10, all ratings
Frame 2…5, all ratings
Frame 6…7, all ratings
Frame 2…7, all ratings
Frame 2…7, all ratings
Temperature, storage (all const.) -40…70 °C (-40…158 °F)
Atmosphere Important: Do not install the drive in an area where the ambient
atmosphere contains volatile or corrosive gas, vapors, or dust. If the drive is
not going to be installed for a period of time, store the drive in an area
where it is not exposed to a corrosive atmosphere.
UV radiation HIM and IP54, NEMA/UL Type 12 drive plastics are not UV rated
Relative humidity, noncondensing 5…95%
Shock, operating
Shock, packaged for shipment
Frame 1…6
Frame 7
Frame 8…10
Frame 1…2
Frame 3…4
Frame 5
Frame 6…10
15 g peak for 11 ms duration (±1.0 ms)
10 g peak for 11 ms duration (±1.0 ms)
Power core - 10 g peak for 11 ms duration
(±1.0 ms) in cabinet with option bay - 5 g peak
for 11 ms duration (±1.0 ms)
381 mm (15 in.) drop height
330 mm (13 in.) drop height
305 mm (12 in.) drop height
Meets international safe transit association
(ISTA) test procedure 2B
Vibration, operating
Vibration, packaged for shipment
Sinusoidal loose load
Random secured
Frame 1…2
Frame 3…5
Frame 6…7
Frame 8…10
Frame 1…5
Frame 6…10
Frame 1…5
Frame 6…10
1.000 mm (0.040 in.) displacement, 2 g peak
1.000 mm (0.040 in.) displacement, 1.5 g peak
1.000 mm (0.040 in.) displacement, 1 g peak
Power core, drive in cabinet with option bay -
1.000 mm (0.040 in.) displacement, 1 g peak
20.0 mm (0.8 in.) peak to peak, 2…5.186 Hz;
1.1 g peak from 5.186…20 Hz
Meets ISTA 2B packaging standards.
Frequency (Hz)
PSD (g
2
/Hz)
1 0.00005
4 0.01
16 0.01
40 0.001
80 0.001
200 0.00001
Meets international safe transit association
(ISTA) test procedure 2B
