Chapter
3
Control the Drive
Enable Keypad Control to Start the Drive
The following steps also serve as a programming example.
1. With the Remote Keypad installed and connected to the Bulletin 160 Series C
drive, power up the drive.
The Remote Keypad always powers up in the Display mode. While in this
mode you may view all
read only drive parameters, but not modify them.
2. Press the Escape key to enter the Program mode.
The Program LED will light and Parameter 30 is displayed.
3. Use the Up or Down arrow key to scroll to P46 - [Input Mode] .
4. Press the Enter key to display the parameter value.
5. Press the Select key to enter the Edit mode.
The Program LED will flash indicating that the parameter value may be
changed.
6. Change P46 - [Input Mode] to 2 or 6 using the Up or Down arrow key.
7. Press the Enter key to save the new value.
The Program LED will stop flashing and remain lit.
Important: When P46 - [Input Mode] is set to 2 or 6, disconnecting the Remote
Keypad will cause the drive to fault.
Save Changes to Parameter 46
In order for changes to P46 - [Input Mode] to take effect, cycle power or set
P56 - [Reset Functions] to 2.
1. Use the Up or Down arrow key to scroll to P56 - [Reset Functions] .
2. Press the Enter key to display the default parameter value of 0.
3. Press the Select key to enter the Edit mode.
4. Change P56 - [Reset Functions] to 2 using the Up or Down arrow key.
5. Press the Enter key to save the new value.
The new P46 - [Input Mode] value is saved and P56 - [Reset Functions] resets to 0.
You can now use the Remote Keypad to start the drive.
Important: The Stop/Reset digital input on the drive (TB3-8) must be
maintained in the ON state for the keypad to start the drive.
