Installation, Drilling pattern and dimensions, Figure 2.1 – Rockwell Automation 160 SSC Remote Keypad User Manual User Manual
Page 13: Chapter
Chapter
2
Installation
Prepare Mounting Location
• Select a mounting location that is less than 5 meters away from the drive.
Connection cables are available in 1, 3, and 5 meter lengths.
• Install in a suitable IP55 or IP65 rated enclosure.
Drilling Pattern and Dimensions
Figure 2.1
ATTENTION:
To guard against electrical shock, disconnect all
power sources before installing or removing.
100
(3.94)
mm
(in)
7.5
(0.30)
135
(5.32)
5
(0.20)
90
(3.54)
140
(5.51)
70
(2.76)
∅
4.5
(0.18)
