Rockwell Automation 21G 750-Series POD Remote Mounting Kit User Manual
Page 14
Rockwell Automation Publication 750-IN015B-EN-P - September 2011
14
PowerFlex 750-Series Control Pod Remote Mounting Kit
2.
If the factory installed control pod was removed from the drive, install the
support brackets provided in Converter Right Cover (no POD) kit (SK-
R1-CCVR2-F8).
3.
Install the Converter Left Cover if removed.
T25 or F - 6.4 mm (0.25 in.)
2.8 N•m (25 lb•in)
