Rockwell Automation 1336S_F_T_E_R C-Frame Front End Conversion Kit User Manual
Page 5
1336 PLUS, PLUSII, IMPACT, and FORCE C-Frame Front End Conversion Kit
5
Figure 1 Drive Components for 1336
-
CONVCF Kit
ab1006a
Bus Cap
Connectors
Snubber Board/SCR
Connector
Snubber Board
Connector
Ground Sense
CT Connector
Power Module
ATTENTION:
Remove the shorting devices before attaching
cables to the Gate Driver Board. Refer to Figure 3.
Connectors
SCR
Connector
End user will remove all of these components from the existing
drive and install on the 1336-CONVCF-SPxA Kit.
Gate Driver Board
Ribbon Cable
Connector
Existing Label
Nameplate
Factory Installed
Add New Label Here,
Customer Installed
1336-CONVCF-SPxA
Thermistor
Connector
HIM
Connector
Interface Board
Connectors
Main
Control
Board
Control
(Optional)
Interface
Board
Heat Sink and
New Label
Factory Installed
1336-CONVCF-SPxA
Fan Assembly
Load Sharing
460V has 1
575V has 2
These components
are included in the
1336-CONVCF-SPxA Kit.
Resistor
Bus Fuse
Bus Capacitor
Bank
Bus Inductor
(Behind Ground
Sense CT)
Snubber Board
and LEMs
