Rockwell Automation 20P PowerFlex DC Drive - Frame A SCR Modules for Drive w/Power Traces Circuit Board User Manual
Page 9
PowerFlex® DC Drive - Frame A SCR Modules for Drives with a Power Traces Circuit Board
9
–
For all other drives, remove the two screws that secure the slotted
air flow plate to the top of the drive and remove the plate.
Important: Mark all connections and wires before removal to avoid
incorrect wiring during reassembly.
=
Air flow plate
Remove screw
Remove screw
