6 ColorSight Series 9000 PHOTOSWITCH
R
Photoelectric Sensor
75027--031--01(A), November 1999
Dip-Switches
A bank of 6 dip-switches are provided for configuring various operating
modes and parameters available with ColorSight. These are defined in the
table below and explained in further detail in the Configuration section on
page 10.
Switch
Label
Function
Switch Up
Switch Down
S1
None
Not used
—
—
S2
/ =
Select target match/no match
Output inactive
Output active
S3
TD/0
Enable/disable time delay
50ms time delay active
No time delay
S4
CI/C
Select color + intensity
mode/color only mode
Color + intensity mode
active
Color only mode active
S5
SG/AV
Select single/average mode
Single sample mode
active
Average sample mode
active
S6
GT/LRN Select gate/remote learn mode
Input functions as gating
input
Input functions as remote
learn
Factory default
Indicators
Three LED indicators are provided to indicate a variety of conditions
making it easy for installation and troubleshooting. The function of each is
described in the table below.
Label
Color
State
Condition
PWR
Green
OFF
Sensor power not present
Steady
Sensor power present
OUTPUT/LEARN
Yellow
OFF
Output inactive
Steady
Output active
Flash
Learn mode activated
FAULT/SCP
Red
OFF
Sensor operating normally
Steady
Marginal detection of target
Flash
Output SCP active
LED also OFF when LEARN pushbutton depressed.
Includes failure to learn color during LEARN process.
