707
Simulator torque no filtering
708
Position 1 detected during reconnect
709
Position 2 detected during reconnect
710
Position 3 detected during reconnect
711
Position 4 detected during reconnect
712
Position 5 detected during reconnect
713
Full stroke average torque
714
Pump off trip level 1, x100
715
Pump off trip level 2
716
Pump off trip level 3
717
Position used when in full stroke average mode
720
Holds speed reference during startup
721
This shows the sleep time used for pump off, it is parameter 183
722
Counts number of times position reconnect restarted
723
Counts number of sleep states, same as parameter 690
728
Elapsed time in current day 0.0001 hours
729
The start time for a 24-hour cycle, used to determine day
730
Pointer to arrays of data
731
(0…13)
• Number of pump off counts in the past 24 hours that the drive was powered.
This changes during the current day.
• Number of pump off counts in the previous 13 days.
The count is pushed down at the end of each day.
Number 1 is the previous day, and 13 is 13 days ago.
732
(0…13) Stroke count for the current 24-hour period. Full stroke count for previous days.
733
(0…23) Stroke count per hour, updated once per hour. “0” is the most current.
734
(0…23) Downstroke or cycle torque, updated once per hour. “0” is the most current.
Test Points (cont.)
Test Point
Description
