26
8. Lists of Exchange Parts
Name of Parts Parts No. Application
Cooling Condenser (A) RG00A-30021 For A type
Cooling Condenser (B) RG00B-30020 For B type
Cooling Condenser (C) RG00C-30021 For C type
Condenser Connector(B) RG00B-30030 Common use for B&C type
Evaporation Flask RG00A-30040 Common use for all types
Receiving Flask RG00A-30050 Common use for all types
Steam Duct RG00A-30011 Common use for all types
Cock 255191-415 Common use for all types
Suction Cock RG00B-40030 For B type
Cooling Condenser Clamp 7060026002 Common use for B & C type (the life is limited)
Receiving Flask Clamp 7060026004 Common use for all types (the life is limited)
Evaporation Flask Clamp 7060026001 Common use for all types (the life is limited)
Teflon Tube (A) 255191-416 For A type L=540mm
Teflon Tube (B) 255192-417 For B&C type L=350mm
Hose Joint RG00A-30030 Common use for all types
Hose Clamp 4320016004 Common use for all types
Ring (Large) RE500-40093 Common use for all types (the life is limited)
Ring (Middle) RE500-40061 Common use for all types (the life is limited)
Ring (Small) RE500-40073 Common use for all types (the life is limited)
O Ring 4210020011 Used to fix Steam duct (the life is limited)
O Ring 4210020012 Used to fix Flask Remover (the life is limited)
Vacuum Seal RE500-40090 Common use for all types (the life is limited)
Fuse (for Body) 2100010011 Φ5.2×20 AC125V 2A
