HEPA/UV3 PCR Workstation and Cabinet Page 2
Introduction
The HEPA/UV3 PCR Systems create an ideal environment for preparing PCR and other samples by
reducing the chance of contamination with the filtered air treated by the HEPA/UV system which blows
into the PCR chamber. The built-in high intensity shortwave (254nm) UV provides a source for
inactivation of DNA between experiments. Additional contamination control is provided by the uniquely
coated stainless steel and aluminum design that maintains antimicrobial efficacy. The surface resists
growth of destructive bacteria, molds, and fungi. Makrolon
® panel assembly blocks UV under 400nm.
Safety Information
The HEPA/UV3 PCR Systems are designed with function, reliability, and safety in mind. Caution: The
units include shortwave UV, which is a powerful source of UV radiation that will cause damage to
unprotected eyes and skin. Before operating, ensure all personnel are properly protected and that
instructions for use of this equipment are followed. A safety shut-off switch automatically turns the UV
light off when the door is open, protecting users from UV exposure. The Makrolon
® panels are specially
formulated to block UV wavelengths below 400nm.
Disconnect the power supply before servicing or fully assembling the PCR system.
Specifications
HEPA/UV PCR MODELS
HEPA UV3 PCR Cabinet HEPA UV3 PCR Workstation
95-0434-01 115V
95-0434-02 230V UK
95-0434-04 230V Euro
95-0434-03 100V 95-0438-01 115V
95-0438-02 230V UK
95-0438-04 230V Euro
95-0438-03 100V
Light Sources:
254nm 8-watt UV:
Filter area
Chamber
UV/air circulator
White – 8-watt:
Chamber Light Sources:
254nm UV:
Filter area 8-watt
Chamber 25-watt
UV/air circulator 8-watt
White – 8-watt:
Chamber
Three stage filters:
Pre-filter
Carbon filter
HEPA filter Three stage filters:
Pre-filter
Carbon filter
HEPA filter
Features include:
Two power outlets
Two small shelves
UV Timer
Antimicrobial coated stainless steel
(work surface) and aluminum
Makrolon
®
panels block
below 400nm
Features include:
Four power outlets
Two shelves
UV Timer
Antimicrobial coated stainless steel
(work surface) and aluminum
Makrolon
®
panels block
below 400nm
Dimensions:
Exterior:
32.5H x 21.4W x 24D in.
(826 x 544 x 610 mm)
Interior: 19.7W x 21.4D in.
(500 x 544 mm) Dimensions:
Exterior:
32.5H x 29W x 24D in.
(826 x 737 x 610 mm)
Interior: 27.8W x 21.4D in.
(706 x 544 mm)
