Frame Parts
Comp 10 2014 (BOOK SIZE) 10.9
Head Jambs
A
3/32”
B (Left Active)
.750”
3.750”
1.505”
2.375”
Detail Cut
Through
R.125 (8)
R .250” (2)
.668”
.750”
3.750”
1.505”
.250”
2.375” .692”
.437”
Detail Cut
Through
.822”
.822”
R.125” (8)
R.250” (2) .693”
.801”
.437”
.363”
Standard MPLS
Impact MPLS
B (Right Active)
A B
407 = 4/0 DOUBLE ASTRAGAL 49.062 21.755
487 = 4/8 DOUBLE ASTRAGAL 57.062 25.755
507 = 5/0 DOUBLE ASTRAGAL 61.062 27.755
547 = 5/4 DOUBLE ASTRAGAL 65.062 29.755
587 = 5/8 DOUBLE ASTRAGAL 69.062 31.755
607 = 6/0 DOUBLE ASTRAGAL 73.062 33.755
707 = 7/0 DOUBLE ASTRAGAL 85.062 39.755
7/
8"
A
S
TR
A
G
A
L
FRENCH DOOR WITH MULTIPOINT LOCK
