Frame Parts

10.20

2014 (BOOK SIZE)

Comp 10

Mullions

Manual Tongue & Variable Height

Lock Mortise Location

.120”

Deep

8.835”

.809”

.147”

.651”

R . 312

1.304”

4.923”

2.608”

2.608”

FULL R

.105” DEEP

.062” DEEP

1.016”

.841”

.651”

.892”

1.016”

2.608”

2.856”

4.641”

.773”

.182”

FULL R

FULL R

FULL R

TONGUE 1

TONGUE 2

STRIKE

UNIT SIZE STRIKE

TONGUE 1 TONGUE 2

6/6

40.101

11.836

67.506

6/8

40.101

11.836

67.506

7/0

44.101

15.836

71.506

8/0

56.101

10.188

83.506

PO

CK

ET

S

TR

IK

E
