SNMP Functionality
In order to accept SNMP messages being sent from the GTRM you will need to have an SNMP
monitoring system in your network or a MIB browser loaded onto your laptop.
Network SNMP Monitoring
For Network SNMP functionality, consult your network administrator for SNMP setup and configuration
parameters and how the GTRM should be configured for your specific SNMP requirements and trap
receivers.
A MIB browser can be used to capture SNMP traps in place of a network SNMP trap receiver The MIB
Browser can be loaded onto a PC or Laptop for monitoring of GTRM SNMP Traps. The MIB browser will
need to be on the same network as the GTRM in order to receive the messages.
SNMP Monitoring through a MIB Browser
A MIB Browser will allow you to accept SNMP messages on any PC or Laptop. A suitable MIB Brower can
be downloaded (FREE Version) from
IMPORTANT: Once the MIB Browser is loaded you will need to load the GTRM MIB file. If you did not
receive this file with your GTRM please contact Ventev innovations or your TESSCO Account Manager to
download the file.
To Install MIB Browser
1. Download MIB Browser from
2. Open MIB Browser Folder
3. Click on the Setup.exe file
4. Click Run and Follow the installation instructions
5. Click Close when the installation has completed
6. Launch the MIB Browser
Install SNMP Traps File
1. In the MIB Browser – Click on the File Tab
2. Select Load MIBs
3. In the Open Window, locate the file called tft_2.mib (This traps file should be located in the
software files included with your GTRM)
4. Click on the tft_2.mib file
5. Click Open
