28
Regency ® CLASSIC C34-3 Direct Vent Freestanding Gas Stove
INSTALLATION
SYSTEM DATA
(For 0 to 4,500 feet altitude)
Orifi ce Sizes:
Burner Natural
Gas #36
Burner Propane #52
Max. Input Rating
Natural Gas
32,000 Btu/h
Propane 32,000 Btu/h
Min. Input Rating
Natural Gas
16,000 Btu/h
Propane 16,000 Btu/h
Supply Pressure
Natural Gas
min. 5.0" w.c
max. 8.0" w.c.
Propane min. 12.0" w.c.
max. 13.0" w.c.
Manifold Pressure High
Natural Gas
3.8" +/- 0.2" w.c.
Propane 11" +/- 0.2" w.c.
Manifold Pressure Low
Natural Gas
1.1" +/- 0.2" w.c.
Propane 2.9" +/- 0.2" w.c.
Electrical: 120V, 1.13A, 60 Hz.
Circulation Fan: 2 speed 75/125 CFM.
Log Set: Ceramic fi ber, 4 per set.
Output capacity:
The effi ciency rating of the appliance is a
product thermal effi ciency rating determined
under continuous operating conditions and
was determined independently of any installed
system.
GAS CONNECTION
The gas connection is a 3/8" NPT rigid pipe.
This pipe is supplied separately and must be
installed at the left rear of the unit. See "Unit
Dimensions" section for diagram. The gas line
can be rigid pipe or to make installation easier,
use a listed fl exible connector and manual shut-
off valve if allowed by local codes, or copper if
approved. For minimum and maximum supply
pressure see the System Data table.
Note: During any pressure testing of the
gas supply piping system that ex-
ceeds test pressures of 1/2 psig, this
appliance and its individual shut-off
valve must be disconnected from
the piping system. If test pressures
equal to or less than 1/2 psig are used
then this appliance must be isolated
from the piping system by closing
its individual manual shut-off valve
during the testing.
HIGH ELEVATION
This unit is approved in Canada for altitude 0
to 4500 ft. (CAN1 2.17-M90) with the orifi ce
supplied.
GAS PIPE PRESSURE
TESTING
The appliance must be isolated from the gas
supply piping system by closing its individual
manual shut-off valve during any pressure
testing of the gas supply piping system at test
pressures equal to or less than 1/2 psig. (3.45
kPa). Disconnect piping from valve at pressures
over 1/2 psig (14" w.c.).
The manifold pressure is controlled by a regulator
built into the gas control, and should be checked
at the pressure test point.
Note: To properly check gas pressure, both
inlet and manifold pressures should
be checked using the valve pressure
ports on the valve.
1) Make sure the valve is in the "OFF" posi-
tion.
2) Loosen the "IN" (# 7) and/or "OUT" (# 6)
pressure tap(s), turning counterclockwise
with a 1/8" wide fl at screwdriver.
3) Attach manometer to "IN" and/or "OUT"
pressure tap(s) using a 5/16" ID hose.
4) Light the pilot and turn the valve to "ON"
position.
5) The pressure check should be carried out
with the unit burning and the setting should
be within the limits specifi ed on the safety
label.
6) When fi nished reading manometer, turn
off the gas valve, disconnect the hose and
tighten the screw (clockwise) with a 1/8" fl at
screwdriver. Screw should be snug, but do
not over tighten.
