Article no. Component Measurement value Comment
80 824 92 Heating element 1950 W Heater 1: 1950 W, 24.5 Ω
80 915 90 Heating element 2500 W Heater 1: 1950 W, 24.5 Ω
Heater 2: 550 W, 91.4 Ω
80 824 91 Heating element 3000 W Heater 1: 1950 W, 24.5 Ω
Heater 2: 1050 W, 45.5 Ω
80 824 60 Heating element 3000 W Heater 1: 1950 W, 90.2 Ω
Heater 2: 1050 W, 167.6 Ω
Marine 440 V
80 824 61 Heating element 3000 W Heater 1: 1950 W, 24,5 Ω
Heater 2: 1050 W, 45,5 Ω
3-Phase
80 916 18 Heating element 2500 W Heater 1: 1950 W, 24,5 Ω
Heater 2: 550 W, 91,4 Ω
3-Phase
80 821 22 Base heat pump complete 50 Hz
80 821 23 Base heat pump complete 60 Hz
80 88 415 Reversing valve 1.9 kΩ
88 015 22
88 015 02
Control unit compl.
TD70.C
Control unit compl.
TD70.C HP/HWC
The control unit contains
microprocessors for controlling
programmes, the motor, the heating
elements etc.
80 846 49 LED-light compl. LED-technology for the machine’s
internal light.
Component description
Components and measurement values cont.
Service Manual TD70.C
10
