Chapter 2 Installation
22
Relays
There are two possible variants:
a) 8 relays in one Relay Output Module.
b) 8x2 (16) relays in one Relay Output Module.
These output are provided for alarms, remote control or energy pulsing, as shown in Figure 2-14 and 15. For
ratings, see Appendix: Technical Specifications.
02-04023
10A
FUSE
1
RELAYS
K1
K2
K3
K4
K5
K6
K7
K8
NC
NC
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
RO
20
10
19
14
17
18
16
15
12
13
11
5
7
8
9
6
3
4
1
2
LOAD
LOAD
LOAD
120-230V AC OR 125V DC LINE
N
SA300
(+)
(-)
Figure 2-14 8-DO Relays Connection
Figure 2-15 16-DO Relays Connection.
Relays 1-6: Form A
Relays 7-8: Form C
