Description – RKI Instruments SC-01 User Manual
Page 9

SC-01 Operator’s Manual
Description • 4
Description
This section describes the components of the SC-01. These components
include the SC-01’s protective rubber boot, case, alligator or belt clip,
sensor retainer, sensor, LCD, control buttons, infrared (IR) communications
port, printed circuit boards, alarm LEDs, buzzer, vibrator, and batteries.
AIR
POWER
LCD
Rubber Boot
DISP
Buzzer
Opening
Sensor
Retainer
Sensor
Alarm LEDs
(Behind Lens)
RKI
IR Port
Battery Cover
Control
Buttons
Figure 1: SC-01 Component Location
