46
RaySafe i2 System User Manual – Safety
IP21
INPUT RATING: 12 V
868,3 M Hz
Model: 8603024
S/N: 0000 0000
Date of M fg
:
01/2010
1.2 A
Raysafe i2 real time display
Designed by Unfors Raysafe
Made in PRC
Figure 18. Real time display label for products sold in the EU
IP21
INPUT RATING: 12 V
927,9 M Hz
Model: 8603027
S/N: 0000 0000
Date of M fg
:
01/2010
Designed by Unfors Raysafe
Made in PRC
Raysafe i2 real time display
1.2 A
R 008-
120016
Figure 19. Real time display label for products sold in Japan
CRAdle pRodUCt lABel
the cradle product label is located on the bottom of the cradle.
B/N: 0000
Model: 8602011
RaySafe i2
cradle
Electrical Safety
E113017
Designed by Unfors RaySafe
Made in PRC
Figure 20. Cradle label
doSIMeteR pRodUCt lABel
the following dosimeter product label is located on the rear side of the dosimeter.
