MacDon DWA for M Series - Manual (Page 43)

REPAIR PARTS
169216 Revision E 41
REF
PART
NUMBER
DESCRIPTION QTY
SERIAL
NUMBER
1 144590 SUPPORT WELDMENT KIT, consists of 176062, Items 2, 15, 58 & hardware. 1 -185859
176062 SUPPORT WELDMENT ............................................................. 1 185860
2 144587 SPACER – 1-1/2” OD x 1” ID x 2-3/4” long ............................... 2
6 176071 DECAL – header position, horizontal format ............................. 2
11 172910 SHAFT ........................................................................................ 1
13 176016 PIN – L ........................................................................................ 1
15 144853 SUPPORT .................................................................................. 1
16 176067 BOLT – hex head, 5/16 NC x 1-3/4 inch TFL GR 5 ZP .............. 2
17 35689 NUT – special (taper facing rod end) ......................................... 4
18 18589 NUT – hex, 5/16 NC ................................................................... 2
21 176066 CYLINDER – gas spring ............................................................. 1
24 103738 CLAMP – PVC insulated 13/16" tube size ................................. 2
25 21491 BOLT – hex head, 1/2 NC x 1.25 LG GR 5 ZP .......................... 2
26 50186 NUT – flange lock, smooth face, dist. thd, 1/2-13 UNC GR 5 .... 6
27 102266 BOLT – RHSSN, 3/4 NC X 4.5 LG GR 5 ZP .............................. 2
29 18601 WASHER – SAE flat, 13/16 ID x 1.5 inch OD ZP ..................... 5
33 18593 NUT – hex, 3/4-10 UNC GR 5 ZP .............................................. 5
34 30896 BOLT – hex head, 3/4-10 UNC x 3.50 LG .................................. 1
35 30549 BOLT – hex head, 3/4 NC x 5.5 LG GR 5 ZP ............................ 1
41 21354 BOLT – hex head, 3/8 NC x 2.0 LG GR 5 ZP ............................ 1
43 30228 NUT – flange, distorted thread, smooth face, 3/8-16 UNC ........ 3
47 20535 WASHER – flat ........................................................................... 2
48 21264 BOLT – hex head, 3/8 NC x 1.25 LG GR 5 ZP .......................... 2
49 16266 PIN – spring, 1/4 dia. x 1.25 LG ................................................. 1
50 2147 PIN – spring, 1/4 dia. x 1.5 LG ................................................... 1
52 21805 FITTING – elbow hydraulic ......................................................... 1
55 144806 HOSE – hydraulic ....................................................................... 1
58 176060 CHANNEL WELDMENT ............................................................. 1
59 18640 WASHER – lock, 3/4 .................................................................. 5
60 18599 WASHER – flat, 17/32 inch I.D. .................................................. 4
61 21880 BOLT – hex head, 1/2 NC x 2.75 long, Gr 5, ZP ........................ 4
