REPAIR PARTS
169216 Revision E 37
REF
PART
NUMBER
DESCRIPTION QTY
SERIAL
NUMBER
7 144833 ROLLER – idler weldment ........................................................... 1
8 144494 ROLLER – drive weldment .......................................................... 1
9 144501 ARM – support ............................................................................ 1
10 144499 ARM – roller support ................................................................... 1
11 176000 ARM – support weldment ............................................................ 1
12 144837 ARM – support rear ..................................................................... 1
13 165735 PIN ASSEMBLY – draper roller .................................................. 3
14 30441 WASHER – hardened ................................................................. 3
15 145249 BOLT – hex head, 5/8 NF x 1.0 LG GR 5 ZP .............................. 3
16 172259 BOLT – shoulder, 3/8-16 UNC .................................................... 4
17 144832 MOTOR – hydraulic M & S 1.52 CI ............................................. 1
132759 SEAL KIT – M & S MOTOR
18 18709 SETSCREW – hex head, socket cup pt 3/8 NC x 5/8 LG ........... 2
19 18664 NUT – hex jam, 3/8-16 UNC GR 5 ZP ........................................ 2
20 120845 SEAL – Nilos LSTO steel disk ..................................................... 3
21 145249 BOLT – hex head, 5/8 NF x 1.0 LG GR 5 ZP .............................. 3
22 30441 WASHER – hardened ................................................................. 3
23 145593 ROD – adjuster weldment ........................................................... 1
24 145345 ROD – adjuster weldment ........................................................... 1
28 144602 PANEL – rear weldment .............................................................. 1
29 172747 SKID – complete with reflectors .................................................. 1
30 115145 REFLECTOR – fluorescent red-orange ...................................... 1
31 115147 REFLECTOR – red ..................................................................... 1
32 145357 BRACKET – idler arm ................................................................. 1
38 144652 BAR – stiffener ............................................................................ 1
39 144851 DEFLECTOR – seal .................................................................... 1
40 144558 BUSHING – steel ........................................................................ 1
41 144597 SEAL – backsheet ....................................................................... 1
42 165304 DRAPER – endless, DWA ........................................................... 1
44 37687 MOULDING ................................................................................. 2
46 18598 WASHER – SAE flat, 13/32 ID x 13/16 inch OD ZP .................. 2
47 19966 BOLT – round head, square neck, 3/8 NC x 1.25 LG GR 5 ZP . 1
48 18604 PIN – cotter 3/32 dia. x 3/4 ZP ................................................... 1
56 50186 NUT – flange, lock, smooth face, dist thd, 1/2-13 UNC ... GR 5 7
57 21471 BOLT – round head, square neck, 1/2 NC x 1.25 GR 5 ZP ....... 1
58 18590 NUT – hex, 3/8-16 UNC GR 5 ZP .............................................. 4
60 11695 WASHER – flat ........................................................................... 3
63 30228 NUT – flange, distorted thread, smooth face, 3/8-16 UNC ........ 15
64 21066 BOLT – round head, square neck, 1/2 NC x 1 GR 5 ZP ............ 1
65 18671 FITTING – lube 1/4-28 UNF ....................................................... 1
66 135157 SCREW – machine .................................................................... 14
67 176063 SHAFT - threaded ......................................................................
1
See NOTE
1
69 18593 NUT – hex, 3/4-10 UNC GR 5 ZP .............................................. 2
70 18689 NUT – hex, lock, distorted thread, 3/4-10 UNC .......................... 2
71 30695 FITTING – hydraulic connector .................................................. 2
72 132867 HOSE – hydraulic ....................................................................... 2
73 176077 HOSE – hydraulic ....................................................................... 1
74 50104 FITTING – elbow 90° hydraulic .................................................. 1
75 135266 FASTENER – cable tie, light blue .............................................. 1
NOTE 1. RE ITEM 67: Prior production units used a hex head bolt in this
location. When replacing bolt with newer design threaded
shaft, also order one each of nuts, items 69 and 70 for
head end.
