MacDon DWA for M Series - Manual (Page 41)

REPAIR PARTS
169216 Revision E 39
REF
PART
NUMBER
DESCRIPTION QTY
SERIAL
NUMBER
4 172746 ARM – decal assembly ............................................................... 1
5 174683 DECAL – warning DWA linkage pinch point, 2 panel ................. 2
8 144592 ARM – front weldment ................................................................ 1
9 144593 ARM – bottom weldment ............................................................ 1
10 144594 CLEVIS – weldment ................................................................... 1
11 172910 SHAFT ........................................................................................ 1
12 176018 SHAFT ........................................................................................ 1
14 176023 SHAFT ........................................................................................ 1
16 109699 SWITCH – snap action ............................................................... 1
17 110845 HARNESS – DWA ...................................................................... 1
18 144826 CYLINDER – hydraulic ............................................................... 1
176031 SEAL KIT – for cylinder
19 172664 CLEVIS ....................................................................................... 1
20 144996 JOINT ASSEMBLY ..................................................................... 1
28 30816 BOLT – round head, square neck, 5/8 NC x 5 TFL GR 5 ZP ..... 1
30 18592 NUT – hex, 5/8-11 UNC GR 5 ZP .............................................. 2
31 176009 WASHER – Nordlock, 3/4" SP ................................................... 4
32 30512 BOLT – hex head, 3/4 NC x 2.0 LG GR 5 ZP ............................ 4
36 18626 PIN – clevis ................................................................................. 1
37 18648 PIN – cotter, 3/16 dia. x 1.25 ZP ................................................ 4
38 20312 PIN – clevis ................................................................................. 1
39 18627 PIN – clevis ................................................................................. 2
41 21354 BOLT – hex head, 3/8 NC x 2.0 LG GR 5 ZP ............................ 4
42 22072 WASHER – flat ........................................................................... 1
43 30228 NUT – flange, distorted thread, smooth face, 3/8-16 UNC ........ 5
44 19966 BOLT – round head, sq. neck, 3/8 NC x 1.25 LG GR 5 ZP ....... 1
45 135158 SCREW – pan head, #6-32 x 3/4 LG ......................................... 2
46 135159 NUT – Nyloc .............................................................................. 2
51 18671 FITTING – lube, 1/4-28 UNF ...................................................... 4
53 30282 FITTING – elbow 90° hydraulic .................................................. 1
54 144805 HOSE – hydraulic ....................................................................... 1
56 176072 DECAL – header position, vertical format .................................. 1
62 172903 TUBE .......................................................................................... 1
63 144870 RAIL WELDMENT ...................................................................... 1
64 139491 PLATE – handrail adapter (M155/M205 only) ............................ 1
65 21449 BOLT – hex head flange (serr. face) ½ NC X 1.0 GR 5 ZP .......
66 50186 NUT – flange lock, smooth face, 0.500-13UNC GR5 .................
67 138744 HARNESS – M205, DWA extension (use if required) ................ 1
176213 KIT – DWA rail adapter
