Default Arduino Pin Mappings
The following table shows how the shield connects your Arduino’s pins to the motor drivers’ pins:
Arduino Pin VNH5019 Driver Pin Basic Function
Digital 2 M1INA Motor 1 direction input A
Digital 4 M1INB Motor 1 direction input B
Digital 6 M1EN/DIAG Motor 1 enable input/fault output
Digital 7 M2INA Motor 2 direction input A
Digital 8 M2INB Motor 2 direction input B
Digital 9 M1PWM Motor 1 speed input
Digital 10 M2PWM Motor 2 speed input
Digital 12 M2EN/DIAG Motor 2 enable input/fault output
Analog 0 M1CS Motor 1 current sense output
Analog 1 M2CS Motor 2 current sense output
See the Pinout portion of Section 4.b for detailed descriptions of the VNH5019 driver pins and Section
5 for a schematic diagram of the shield. See Section 6.a for instructions on how to customize your
board’s Arduino pin mappings if the above defaults are not convenient.
