1 - RS485 Data line resistance check - ACU not responding or fails to be detected.

Q

First power down any data line converters and disconnect any ACU's that do not have a flashing OK LED. Using a

Q

Multimeter, measure the resistance across the White/Green and Green pair at one end of the network.

Q

A resistance of between 60 and 80 ohms is required. Repeat the test for the White/Orange and Orange pair.

Q

This is vital for a stable and trouble free installation.

2 - ACU Reset - No OK LED flashing.

Q

The ACU has no factory reset condition as it does not contain any fixed settings. The unit does have an operating

Q

program (firmware) that controls its functions and can be confirmed as running by means of the flashing OK LED.

Q

- If the OK LED is flashing steadily, then there should be no reason to reset the unit.

Q

- If the OK LED is not flashing, you need to clear the unit so that it can receive a firmware download from the PC.

Q

Any other ACU's without OK LED's must be taken off the line or powered down.

Q

1. Stop Net2 Server (Net2 server icon - Bottom right of screen - Right mouse click, Select Stop the Net2 Server).

Q

2. Power down the Net2 ACU.

Q

3. Insert a link wire between the Orange and Mauve terminals on reader 2 port.

Q

4. Power up the ACU. - The OK LED flashes very quickly.

Q

5. With the unit still powered, remove the link.

Q

6. Go to the PC and Start the Net2 Server and go into the Doors screen. Click on the Detect button. This

Q

should look for the ACU and then download its firmware (This may take up to 5 minutes). - The OK LED

Q

should now be flashing with a steady heartbeat. This procedure must only be done for one ACU at a time.

Q

NOTE: If this unit is using the TCP/IP interface, any fixed IP settings will be retained.

Q

If the unit is in DHCP mode it will need to be detected at each stage using the Net2 Server Config Utility

Q

as a new address may be issued by the IP server, each time the PCB resets.

3 - Can we use a DHCP IP address?

Q

The Ethernet interface does support DHCP, but for more reliable communication, a static IP address must be

Q

reserved for the unit. This is because some servers issue different DHCP addresses each time they are restarted

Q

and this requires the Net2 interface to be manually set up again - a time consuming process.

4 - TCP/IP - Direct PC connection.

Q

Connect the network interface directly to the LAN port of the PC. Without the presence of a DHCP server the unit

Q

will default to an IP address in the range 169.254.X.X.

Q

Check the IP address of the network card of your PC by typing IPCONFIG at the command prompt. Detect the

Q

TCP/IP interface with the Net2 Server Configuration Utility and change the IP address to an address

Q

similar to that of your machine. For example, if the IP address of the PC is 192.168.10.7, change the IP address

Q

of the TCP/IP interface to 192.168.10.8. Once the IP address of the interface has been changed into the range of

Q

the PC then Net2 will be able to communicate with it.

Q

NOTE: Do not change the IP address of your PC to 169.254.x.x, this will not allow the IP address of the TCP/IP

Q

interface to be fixed correctly.

5 - Cannot detect ACU via a TCP/IP interface.

Q

1. The TCP/IP interface must be listed in the Net2 Server Configuration Utility, and responds when PINGed

Q

from the utility. A static IP address must be used for the interface.

Q

2. If the interface is responding, try a loopback test. (see Loopback section)

Q

3. The Net2 data line should be checked for resistance readings.

6 - Readers/Keypads not working.

Q

- Software settings - Confirm that the settings of the reader or keypad are correct.

Q

- Connections - Check the wiring and integrity of the connectors. - If possible, test this reader on the other port.

Q

- Cable - Belden 9540 should be used to extend the reader cable (100 m maximum). Twisted pair alarm cable

Q

should not be used. To confirm that a cable extension is not at fault, wire the reader direct into the reader port.

Q

- Supply voltage - Confirm that the voltage is within specification. (see table)

Q

- User token - Confirm that the user token used for testing is OK by presenting it to a known working reader.

Q

- Interference - Confirm whether the reader works when tested 'in hand' and not mounted on the wall. Ensure

Q

that readers are not mounted back to back or there is no interference from other local RF devices.
