Paxton Net2 PaxLock - Scandic - Manual

Page 1
27/08/2013
Parts list
Tools List
Power Drill
Drill bits 10 mm, 16 mm
Philips screwdriver
Small flat blade terminal screwdriver
Pencil
3mm Hex key (supplied)
Ins-30209 Net2 PaxLock - Scandic
This wireless unit requires a Net2Air bridge
to communicate with the server PC.
Paxton
1) Front Lock Assembly
2) Rear Lock Assembly
3) Handle Rose x 2
4) Door Handle x 2
1 2 3
4
5
6
7
8 9
10 11
AA AA
- -
+ +
12
5) Mounting screw ( 35 mm ) x 2
6) Mounting screw ( 45 mm ) x 2
7) Mounting screw ( 55 mm ) x 2
8) 8 mm Spindle
9) Thumb Turn Follower
10) AA battery x 4
11) 3 mm Hex Key
12) Cover plate x 2
Technical Support
Technical help is available: Monday - Friday from 07:00 - 19:00 (GMT)
Saturday from 09:00 - 13:00 (GMT)
01273 811011 [email protected]
Documentation on all Paxton products can be found on our website - http://www.paxton.co.uk/
