Operation
24
Optical output
There are three operation modes available for the optical out-
put:
2 channel mode (AES)
ADAT mode (8 channels)
Channels 1, 3, 5, 7 are fed from channel A of the
stereo signal , while channels 2, 4, 6, 8 contain the
audio of channel B
Optical output is switched off
You may alter settings as follows:
1. Select the value under the LED icon with the rotary
wheel:
2. Press “ENTER“ to change the value.

You have configured the optical output
The optical output can operate up to the
following maximum sampling frequencies:
2 channel mode: 106 kHz
ADAT:
55 kHz
At any selected sampling frequency higher
than the given limits the optical output is
automatically disabled and the visual icon
indicators behind the symbol will not be
present:
