dca300sscu2/4i 60 hz generator• operation manual — rev. #1 (10/21/13) — page 89
eNCLOsUre assy.
ADD THE FOLLOWING DIGITS AFTER THE PART
NUMBER WHEN ORDERING ANY PAINTED PANEL TO
INDICATE COLOR OF UNIT:
1-ORANGE
6-CATERPILLAR YELLOW
2-WHITE 7-CATO GOLD
3-SPECTRUM GREY 8-RED
4-SUNBELT GREEN 9-DESERT TAN
5-BLACK
THE SERIAL NUMBER MAY BE REQUIRED.
no. part no. part name qtY. remarKs
1 M5413000302 BASE 1
2 M1413400004 FLOOR PANEL 1
3 M5413100204 FLOOR PANEL 1
4 0019208020 HEX. HEAD BOLT 12
5 M5413600204 DUCT 1
5A M5493000104 ACOUSTIC SHEET 1
6 011008020 HEX. HEAD BOLT 4
7 M5423000602 FRONT FRAME 1
7A M5493103403 ACOUSTIC SHEET 1
8 M5423000702 FRONT FRAME 1
8A M5493103403 ACOUSTIC SHEET 1
9 011008020 HEX. HEAD BOLT 10
10 0017110025 HEX. HEAD BOLT 8
11 M5423200503 COVER, FRONT FRAME 1
12 0019208020 HEX. HEAD BOLT 12
13 M5423200603 COVER, FRONT FRAME 1
13A M5494103504 ACOUSTIC SHEET 1
14 0019208020 HEX. HEAD BOLT 12
15 M5433000202 CENTER FRAME 1
16 0010114050 HEX. HEAD BOLT 4
16A 515455840 HEX. NUT 4
16B 030214350 WASHER, LOCK 4
16C 031114260 WASHER, FLAT 8
17 Y0010114040 HEX. HEAD BOLT 8
17A 515455840 HEX. NUT 8
17B 030214350 WASHER, LOCK 8
17C 031114260 WASHER, FLAT 16
18 M5433400004 BRACKET 1
19 0016910030 HEX. HEAD BOLT 2
20 M5336700204 COVER 1
21 0019208020 HEX. HEAD BOLT 2
22 M5443000302 REAR FRAME 1
22A M5493300904 ACOUSTIC SHEET 2
23 0017110025 HEX. HEAD BOLT 4
24 M5443300303 COVER, REAR FRAME 1
24A M5493301504 ACOUSTIC SHEET 1
25 M5443300404 PANEL 1
25A M5493301604 ACOUSTIC SHEET 3
