dca300sscu2/4i 60 hz generator• operation manual — rev. #1 (10/21/13) — page 73
no. part no. part name qtY. remarKs
40 0601807622 FREQUENCY METER, 45-65HZ 240V 1
41 0601806979 AC AMMETER, 500A/1000A:5A 1
42 0601801040 CHANGE-OVER SWITCH, AMMETER 1
43 0601806887 AC VOLTMETER, 0-600V 1
44 0601801041 CHANGE-OVER SWITCH VOLTMETER 1
45 0601810072 PILOT LAMP, 220V 1
45A 0601810261 BULB, 13W 1
46 0601840073 RHEOSTAT (VOLT. REG.), 2W 1K OHM 1
46-1 0601840100 KNOB 1
47 0601830710 SWITCH 2
48 0601810171 PANEL LIGHT, DC 24V 1
49 0027104020 MACHINE SCREW 2
49A OEMAA8 HEX. NUT 2
50 82608 SWITCH 1
51 0601831557 STOP BUTTON 1
52 0601831205 SWITCH 1
53 Y0602202642 CONTROLLER ECU 1
54 Y0602120569 GAUGE ASSY. 1
55 M9220100004 SET SCREW 2
55A 0080200007 SNAP RING 2
56 0017108040 HEX. HEAD BOLT 4
57 M5214500004 COVER, CONTROL BOX 1
58 011008020 HEX. HEAD BOLT 8
59 M5214300004 SIDE PANEL, CONTROL BOX 1
60 011008020 HEX. HEAD BOLT 4
61 M5213400104 PANEL, CONTROL BOX 1
62 011008020 HEX. HEAD BOLT 9
63 0016910030 HEX. HEAD BOLT 5
63A OEMAA8 HEX. NUT 5
64 Y0601806646 FUSE, 20A 1
65 Y0017112040 HEX. HEAD BOLT 6
65A 0030012000 HEX. NUT 6
65B 031112230 WASHER, FLAT 6
66 Y0017112040 HEX. HEAD BOLT 3
66A 0030012000 HEX. NUT 3
66B 031112230 WASHER, FLAT 3
67 Y0601872130 FUSE HOLDER 1
67A Y0601806603 FUSE 1
68 0027104020 MACHINE SCREW 2
69 Y0206707000 HEX. NUT 8
69A Y0044807000 WASHER, LOCK 8
70 M5246700804 WIRE HARNESS. GENERATOR 1
71 M5357200302 WIRE HARNESS. ENGINE 1
CONtrOL bOx assy. (CONtiNUeD)
