dca300sscu2/4i 60 hz generator• operation manual — rev. #1 (10/21/13) — page 71
CONtrOL bOx assy.
no. part no. part name qtY. remarKs
1 M5213000202 CONTROL BOX 1
2 0601809659 CURRENT TRANSFORMER, 500/5A 3
3 0027106016 MACHINE SCREW 6
4 Y0601807519 CIRCUIT BREAKER, 800A 1
4-1 Y0601827410 BUS BAR 2
5 M5261600004 BRACKET, CIRCUIT BREAKER 1
6 011008020 HEX. HEAD BOLT 4
7 0601820604 AUTOMATIC VOLTAGE REGULATOR 1
8 0027105016 MACHINE SCREW 4
9 M5273000103 CHANGE-OVER BOARD VOLTAGE 1
10 M5276400104 CHANGE TERMINAL 10
11 011208030 HEX. HEAD BOLT 20
12 M5276200004 TERMINAL PLATE 3
13 M5276300104 CHANGE PLATE 6
14 M9220101104 HEX. HEAD BOLT 13
15 M2233100004 HEX. HEAD BOLT 13
16 0040012000 WASHER, LOCK 26
17 0041412000 WASHER, FLAT 26
18 012010030 HEX. HEAD BOLT 4
19 0601820847 OVER CURRENT RELAY 1
20 0601820848 OVER CURRENT RELAY 1
21 0027104020 MACHINE SCREW 2
21A OEMAA8 HEX. NUT 2
22 0601815153 TERMINAL BOARD 1
23 0027104020 MACHINE SCREW 2
24 0601802218 HOLDER, FUSE 1
24A 0601806671 FUSE (LEFT SIDE), 15A 1
24B 0601802131 FUSE (CENTER), 1A 1
24C 0601802133 FUSE (RIGHT), 5A 1
25 0027103020 MACHINE SCREW 2
26 M4213600104 STOPPER CONTROL PANEL 1
27 952404470 WASHER, FLAT 1
28 505015300 SNAP PIN 1
29 M5260500303 SET PANEL, ELECTRIC PARTS 1
30 011008020 HEX. HEAD BOLT 4
31 LY2DUS24VDC RELAY, 24V 1
31A PTF08A SOCKET 1
31B PYCA1 HOLDER 1
32 0027104020 MACHINE SCREW 2
33 0601821370 RECTIFIER 2
34 0027104020 MACHINE SCREW 2
35 Y0602201457 RELAY, HEATER 1
36 0016906016 HEX. HEAD BOLT 2
37 M5223000304 CONTROL PANEL 1
38 M5223000204 CONTROL PANEL 1
39 0605011211 PIN 2
