page 12 — dca300sscu2/4i 60 hz generator • operation and parts manual — rev. #1 (10/21/13)
speCifiCatiONs
table 1. generator specifications
model DCA300SSCU2/ DCA300SSCU4i
Type
Revolving field, self ventilated,
open protected type synchronous generator
armature connection star with Neutral
phase 3
standby Output 264 kW (330 kVA)
prime Output 240 kW (300 kVA)
3Ø voltage (l-l/l-n)
voltage change-over Bd. at 3Ø 240/139
208Y/120, 220Y/127, 240Y/139
3Ø voltage (l-l/l-n)
voltage change-over Bd. at 3Ø 480/277
416Y/240, 440Y/254, 480Y/277
1Ø voltage (l-l/l-n)
voltage change-over Bd. at 1Ø 240/120
240/120
power Factor 0.8
Frequency 60 Hz
speed 1800 rpm
aux. ac power Single Phase, 60 Hz
aux. voltage/output 4.8 Kw (2.4 kW x 2)
dry Weight 8,642 lbs. (3,920 kg)
Wet Weight 9,766 lbs. (4,440 kg)
table 2. engine specifications
model Cummins QSL9-G8 Interim Tier 4 Certified
Type
4 cycle, water-cooled, direct injection, turbo-charged
charged air cooled and EGR
no. of cylinders 6 cylinders
Bore x stroke 4.49 in. x 5.71 in. (114 mm x 145 mm)
displacement 543 cu. in. (8.9 liters)
Rated Output 433 HP @1800 rpm
starting Electric
coolant capacity 1 14 gal. (53.0 liters) 1
lube oil capacity 2 6 gal. (22.7 liters) 2
lubricating type oil API service class CJ-4 SAE 15W-40
Fuel Type #2 Diesel Fuel (Ultra low sulfur diesel fuel only)
Fuel Tank capacity 129 gal. (380 liters)
Fuel consumption
16.3 gal. (61.8 L)/hr at full load 14.1 gal. (53.3 L)/hr at 3/4 load
12.0 gal. (45.5 L)/hr at 1/2 load 7.05 gal. (26.7 L)/hr at 1/4 load
Battery 12v 150Ah X 2 (24 V System)
1 Includes engine and radiator hoses
2 Includes filters
