page 14 — JTNS20H/SW20H-SeRIeS RIDe-ON pOWeR TROWeL • OpeRaTION maNuaL — Rev. #4 (10/15/13)
specifications/dimensions
Table 2. JTNSW20HTCSL Noise and vibration emissions
model JTNSW20HTCSL
Guaranteed ISO 11201:2010 Based
Sound Pressure Level at Operator Station in dB(A)
90.84
Guaranteed ISO 3744:2010 Based
Sound Power Level in dB(A)
115.66
Whole Body Vibration Per ISO 2631-1:1997+A1:2010 in m/s 2 SA(8) 0.06
Table 3. Engine Specifications/Dimensions
model Honda gX630 RH QZB2-R280 engine
Type
4 Stroke, Overhead Valve, 90° V-Twin
2 cylinder gasoline engine.
Bore x Stroke 78 x 72 mm (3.1 x 2.8)
Piston Displacement 688 cc (41.9 cu.in).
Net Power Output 15.5 kW (20.8 HP/3,600 rpm)
Max. Torque
48.3 N.m (4.93 kgf.m 35.6 lbf.ft)
@ 2,500 rpm
Cooling System Forced Air
Engine Oil Capacity
SAE 10W-30 API Service Class SE or later
1.6 qt. (1.50 liters)
1.8 qt. (1.7 liters w/oil filter replacement)
Fuel
Unleaded gasoline
Octane rating of 86 or higher.
Maximum 10% ethanol.
See engine manual for further details.
Fuel Consumption 6 liters/hr.@ 3600 RPM
Starting System Electric Start/CDI Type Magneto Ignition
Spark Plug Type ZFR5F NGK
Spark Plug Gap 0.70 - 0.80 mm (0.028-0.031 in.)
L x W x H 405 x 410 x 438 mm (15.9 x 16.1 x 17.2 in.)
Weight (dry) 44.4 kg (97.8 lbs.)
NOTES:
1. Sound Pressure and Power Levels are “A” weighted Measures per ISO 226:2003 (ANSI S1.4-1981). They are measured with the operating
condition of the machine which generates the most repeatable but highest values of the sound levels. Under normal circumstances, the sound
level will vary depending on the condition of the material being worked upon.
2. The vibration level indicated is the vector sum of the RMS (Root Mean Square) Values of amplitudes on each axis, standardized to an 8 hour
exposure period, and obtained using operating condition of the machine that generates the most repeatable but highest values in accordance
with the applicable standards for the machine.
3. Per EU Directive 2002/44/EC, the daily exposure action value for whole body vibration is 0.5 m/s 2 SA(8). The daily exposure limit value is
1.15 m/s 2 SA(8).
