System Specifications
MTS Criterion™ Series 60 Site Preparation 15
Note When performing a test, the actuator will extend, which makes the frame
overall height higher than the height listed in the above table. Take the
actuator stroke into account when preparing the facility.
Environmental
requirements
All MTS Criterion 60 load frames are intended for indoor use only. This indoor
environment must conform to the following environmental specifications.
Note All MTS Criterion 60 load frames must only be operated under the
installation and ambient conditions (such as, temperature and moisture)
specified.
MTS Criterion 60 Load Frame Specifications (Continued)
M ODEL B ASE W IDTH
(A)
B ASE D EPTH
(B)
O VERALL H EGHT
(C)
A CTUATOR
(P ISTON ) S TROKE
W EIGHT
64.305EL 870 mm
(34.25 in)
725 mm
(28.54 in)
2470 mm
(97.24 in)
150 mm
(5.91 in)
2003 kg
(4416 lb)
64.605EL 1170 mm
(46.06 in)
800 mm
(31.50 in)
2780 mm
(109.45 in)
200 mm
(7.87 in)
3254 kg
(7174 lb)
64.106EL 1310 mm
(51.57 in)
910 mm
(35.83 in)
3130 mm
(123.23 in)
250 mm
(9.84 in)
5400 kg
(11905 lb)
P ARAMETER S PECIFICATION
Temperature 5ºC–40ºC (41ºF–104ºF)
Humidity 10–85%, non-condensing
Altitude 2000 m (6,561 ft) maximum
