Swift 50 glp mechanical drawings, Swift 50 glp mechanical drawings 95 – MTS SWIFT 50 GLP Sensor Heavy Trucks User Manual
Page 95
SWIFT 50 GLP Mechanical Drawings
SWIFT 50 GLP Sensors
Assembly Drawings
95
SWIFT 50 GLP Mechanical Drawings
SWIFT 50 GLPS Mechanical Drawings
Part Number
Part Description
569844xx
LUG NUT, MODIFICATION-SWIFT 50GLP
570594xx
CONDUIT BRKT- SLIP RING ASSY-SWIFT 50GLP
100161435
ANTI-ROTATE ASSY- CUST/USER,SWIFT 50GLP
700002218
DISK RIM (FRT) CUSTOMER DIMENSIONAL DWG
700002219
DISK RIM (REAR) CUSTOMER DIMENSIONAL DWG
700002520
ANTI-ROTATE BRKT WELDMENT-SWIFT 50 REF
700003435
REFERECE DIMENSION ASSEMBLY-SWIFT 50GLP
700003439
SWIFT 50GLP MOMENT LDS DETERMINATION DWG
700003458
REFERENCE-SPINDLE SPACER, SWIFT 50GLP
