SWIFT 50 GLP Sensors
24
Specifications
Hardware Overview
Specifications
SWIFT 50 GLP Transducer Performance (part 1 of 2)
Parameter
Specification
Use
SWIFT 50 GLP S (stainless steel) for
SWIFT 50 GLP T (titanium) for
high fatigue life, durability
low weight, high sensitivity
Maximum usable rpm
2,200
Maximum speed
200 kph (125 mph)
Fits rim size (usable range)
22.5–24.5 inch
*
Maximum hub bolt circle diameter
accommodates M22 studs
335 mm (13.189 in)
Input voltage required (mini TI)
10–28 V DC
Input power required (mini TI)
8 W maximum (6 W typical)
Output voltage ± full scale calibrated load
±10 V
†
SAE J267
Rated load capacity
‡
Bending moment
§
Stainless SteelTitanium
64.50 kN (14,500 lbf)44.48 kN (10,000 lbf)
55.8 kN•m (494,075 lbf•in)38.5 kN•m (340,740 lbf•in)
Full scale calibrated ranges
#
Longitudinal force (Fx)
±220 kN (±49,458 lbf) ±150 kN (±33,721 lbf)
Lateral force range (Fy)
±100 kN (±22,481 lbf) ±60 kN (±13,489 lbf)
Vertical force range (Fz)
±220 kN (±49,458 lbf) 150 kN (±33,721 lbf)
Overturning moment (Mx)
±50 kN•m (±442,537 lbf•in) ±37 kN•m (±327,478 lbf•in)
Driving/braking moment (My)
±50 kN•m (±442,537 lbf•in) ±40 kN•m (±354,030 lbf•in)
Steering moment (Mz)
±50 kN•m (±442,537 lbf•in) ±37 kN•m (±327,478 lbf•in)
Resolution (analog system)
Infinite
Noise level (peak-to-peak 0-500 Hz)
40 N (9.0 lbf) 30 N (6.7 lbf)
Performance accuracy
Nonlinearity
1.0% full scale
Hysteresis
0.75% full scale
Modulation
**
≤5.0% reading
Cross talk
††
1.5% full scale
