47
MK-101 PaRTS liST
item Description Part # Qty
1 SCREW, 5/16 - 18 X 1/2 SOCKET HD SET 152607 3
2 ELBOW, 1/8MNPT X 1/4 BARB, 90 DEG 154652 1
3 TUBE, WATER 155389 2
4 CASTING, 101 BLD GUARD-DC-COMP 162481 1
Blade Guard assembly Part# 152582
item Description Part # Qty
1 WHEEL, ROLLER 151799 1
2 NUT, HEX, 1/4 - 20 151893 1
3 SCREW, HEX HEAD 1/4 -20 X 1-1/2" 151914 1
4 WASHER, 1/4 SAE FLAT 151915 1
5 BRACKET, ROLLER WHEEL 154021 1
Roller wheel assembly Part# 151756
