15
MK-101 TRaNSPORT
The MK-101 weighs approximately ninety-two (92) pounds; follow the guidelines for transport in the
TRANSPORT section, when placing it on the stand.
NOTe: If using the MK Diamond stand, follow the following steps.
(C)
Ensure saw frame is positioned
correctly
(D)
Reinstall the Water Basin
(A)
Open the Stand and place on
flat surface
(B)
Remove Water Basin and place
saw on stand
Cutting Head
Lift Point
Lift Point
Lift the saw using the
lift points shown.
1. The MK-101 weighs approximately ninety-two (92) pounds.
2. Never transport the MK-101 with water in the Water Basin.
The MK-101 is designed with a rigid frame and removable Cutting Head. Two people are required
to transport the MK-101 with the Cutting Head installed. Remove the Cutting Head if one person is
transporting the saw (see Cutting Head Installation and Removal in the following section).
CAUTION
TRaNSPORT
STaND
