Metal Sales Secondary Framing - Manual (Page 51)

PSF-51
Secondary Framing
© Metal Sales Manufacturing Corporation/ Subject to change without notice/ Effective Date 9/11
800.406.7387 (Corporate Office) • www.metalsales.us.com
lGsi Z
ee
l
aP
i
nformaTion
(
ConT
.)
LgSi Long LaP
LgSi maX LaP
LgSi SUPer LaP
For required lap condition use standard
punch pattern #A, #D, or #F.
For required lap condition use standard
punch pattern #A, #D, or #G.
For required lap condition use standard
punch pattern #B, #E, or #H.
2' - 3 1 /
2
" Lap
4' - 3 1 /
2
" Lap
6' - 3 1 /
2
" Lap
2" 2"
2" 2"
2" 2"
3'-0" 3'-0"
2'-0" 2'-0"
1'-0" 1'-0"
For Zees Only
For Zees Only
For Zees Only
