Secondary framing – Metal Sales Secondary Framing User Manual
Page 3
PSF-3
Secondary Framing
© Metal Sales Manufacturing Corporation/ Subject to change without notice/ Effective Date 9/11
800.406.7387 (Corporate Office) • www.metalsales.us.com
P
urlin
and
G
irT
a
TTaChmenT
(
ConT
.)
The drawing below represents girts outside the column attached with bolts direct to the column. Purlins are shown with typical
lap condition bolted to the beam with a clip.
7'-6"
girt
Beam
Purlin bolted to beam with clip
High strength bolt
Fin head bolt
Tapered column
Eave strut
Bracing
Foundation
Base angle
Anchor bolt
