P
unChinG
s
ellersburG
, i
ndiana
line
only
Custom punching can be done for Standard
Cees, Zees, LGSI Zees, and Eave Struts.
Web punching is available in 4" to 12" Cees,
Zees, and Eave Struts. Punching is available
only on center line of web for 4" member.
Flange punching is available in 6" to 12" Cees,
Zees, and Eave Struts only.
FLange PUncHing
Flange punching can be punched in either "X" or "Z".
"X" must be 1
1
/
4
", 1
3
/
4
", or 2" from web.
"Z" must be 2
1
/
4
", 3", or 4" from web.
Any combination of punching (1-11)
can be punched together.
Both holes or slots in 3, 4, 5, 6, 7, 10, and 11
must be punched together.
5
/
8
" Round Holes
5
/
8
" x
3
/
4
" Vertical Slots
3" spacing required between
holes or slots in flanges.
3"
3"
1 2
3 4
5 6
7
8
9 10
10
11
11
1"
1"
1"
1"
"X""Z"
cL
"X"
"Z"
Flange width must be 2
7
/
8
", 3", 3
3
/
8
",
3
1
/
2
", 3
7
/
8
", 4", or 5" for punching
second holes or slots ("Z").
Flange
Web
LGSI Short
Flange
cee or
eave Strut
cL
"X"
Flange
Zee
