Metal Sales Secondary Framing - Manual (Page 16)

PSF-16
Secondary Framing
© Metal Sales Manufacturing Corporation/ Subject to change without notice/ Effective Date 9/11
800.406.7387 (Corporate Office) • www.metalsales.us.com
C
usTom
P
unChinG
J
aCksonville
, f
lorida line only
Custom punching can be done for Standard
Cees, Zees, LGSI Zees, and Eave Struts.
Web punching is available in 4" to 12" Cees,
Zees, and Eave Struts. Punching is available
only on center line of web for 4" member.
Flange punching is available in 6" to 12" Cees,
Zees, and Eave Struts only.
Flange punching can be punched in either "X" or "Z".
"X" must be 1 1 /
4
", 1 3 /
4
", or 2" from web.
"Z" must be 2 1 /
4
", 3", or 4" from web.
FLange PUncHing
5 /
8
" Round Holes
5 /
8
" x 3 /
4
" Vertical Slots
3" spacing
required between
holes or slots in
flanges.
3"
3"
1"
1"
1"
1"
cL
"X"
"Z"
Any combination of punching with the exception
of (8) can be punched together.
Both holes or slots in 3, 4, 5, 6, 7, 8, 14, and 15
must be punched together.
All four holes or slots in 9, 10, and 11 must be
punched together.
1 2
3 4
5 6
7
8
9
10
12
13
8
9
10 11
11
3"
4"
4"
4"
Web
LGSI Short
Flange
cee or
eave Strut cL
"X"
Flange
Zee
"X"
"Z"
Flange width must be 2 7 /
8
", 3", 3 3 /
8
",
3 1 /
2
", 3 7 /
8
", 4", or 5" for punching
second holes or slots ("Z").
Flange
15
14
