Metal Sales Secondary Framing - Manual (Page 37)

PSF-37
Secondary Framing
© Metal Sales Manufacturing Corporation/ Subject to change without notice/ Effective Date 9/11
800.406.7387 (Corporate Office) • www.metalsales.us.com
Span in
Feet
Section
Long Lap - 2 Spans
Z-
8" x 3 1 /
2
"
Stress
Controlling, plf
12 Ga 14 Ga 12 Ga 14 Ga
Defl. (L/180)
Controlling, plf
18 169 289 215 367
Long Lap - 3 Spans
Stress
Controlling, plf
Defl. (L/180)
Controlling, plf
12 Ga 14 Ga 12 Ga 14 Ga
20 136 229 173 290
22 112 186 142 235
24 93 154 118 194
25 86 141 108 178
26 79 129 100 163
28 68 110 85 139 134
30 58 95 74 120 73 108
Notes:
1. Tabulated values are allowable superimposed loads. Purlin and all other load weights have not been subtracted from them.
2. Allowable loads have been calculated in accordance with 2001 AISI Specifications.
3. Bearing must be checked using actual bearing length and loads.
4. Wind loads can be obtained by multiplying tabulated values by 1.33.
5. Tabulated values are valid only if the compression flange of the section is adequately supported laterally.
a
lloWable
u
niform
l
oads in
P
ounds Per
l
inear
f
ooT
Load TaBLeS For STandard ZeeS (Symmetrical Flanges Only)
2'-4" Lap
Flange
Web
Flange
Long Lap
Span in
Feet
Section
Long Lap - 2 Spans
Z-
8" x 3"
Stress
Controlling, plf
12 Ga 14 Ga 12 Ga 14 Ga
Defl. (L/180)
Controlling, plf
18 165 292 211 370
Long Lap - 3 Spans
Stress
Controlling, plf
Defl. (L/180)
Controlling, plf
12 Ga 14 Ga 12 Ga 14 Ga
20 133 231 169 293
22 109 188 138 238
24 91 155 115 196 193
25 83 142 106 180 171
26 77 131 97 165 146
28 66 111
83 141 81 121
30 57 96 72 121 66 98
