Page 18
PPL-18
PRO-LOC I,II
© Metal Sales Manufacturing Corporation/ Subject to change without notice/ Effective Date 9/11
800.406.7387 (Corporate Office) • www.metalsales.us.com
g
ravel
s
ToP
d
eTail
C
oPing
d
eTail
Pro-loC i,ii
3:12 SLOPE
MINIMUM
Pro-Loc Z-Closure
#10-12 x 1" PHW (4 per panel)
Tube Sealant
Fastener (by others)
Gravel Stop
Double Bead Tape Sealant
Pro-Loc Z-Closure
#10-12 x 1" PHW (4 per panel)
Tube Sealant
Double Bead Tape Sealant
Coping
Pro-Loc Panel
Double Bead Tape Sealant
1
/
8
x
3
/
16
" Pop Rivet (1'-0" o.c.)
1
/
8
x
3
/
16
" Pop Rivet (1'-0" o.c.)
Pro-Loc Wall Panel
NOTE: Z-Closures must be field cut and bent to fit between panel ribs
(See Metal Sales Architectural Installation Manual).
NOTE: Z-Closures must be field cut and bent to fit between panel ribs
(See Metal Sales Architectural Installation Manual).
