PPL-14
PRO-LOC I,II
© Metal Sales Manufacturing Corporation/ Subject to change without notice/ Effective Date 9/11
800.406.7387 (Corporate Office) • www.metalsales.us.com
r
ake
(o
ff
m
odUle
) d
eTail
r
akewall wiTh
C
oUnTer
f
lashing
d
eTail
Pro-loC i,ii
Pro-Loc Panel (field bend and cut)
Double Bead Tape Sealant
Rake
#10-12 x 1" PHW (1'-0" o.c.)
Cleat
1 /
8
x 3 /
16
" Pop Rivet (1'-0" o.c.)
Pro-Loc Z-Closure
#10-12 x 1" PHW (1'-0" o.c.)
Pro-Loc Panel (field cut and bend)
Double Bead Tape Sealant
1 /
8
x 3 /
16
" Pop Rivet (1'-0" o.c.)
Pro-Loc Z-Closure
#10-12 x 1" PHW (1'-0" o.c.)
Pro-Loc Rakewall
Tube Sealant
Fasteners (by others)
Counter Flashing
Moisture Barrier (by others)
Double Bead Tape Sealant
