PPL-13
PRO-LOC I,II
© Metal Sales Manufacturing Corporation/ Subject to change without notice/ Effective Date 9/11
800.406.7387 (Corporate Office) • www.metalsales.us.com
Pro-loC i,ii
s
loPe
C
hange
d
eTail
r
ake
(o
n
m
odUle
) d
eTail
3:12 SLOPE
MINIMUM
Pro-Loc Inside Closure
Pro-Loc Panel
Moisture Barrier (by others)
Double Bead Tape Sealant
Double Bead Tape Sealant
#10-12 x 1" PHW (1'-0" o.c.)
Pitch Break
Offset Cleat
#10-12 x 1" PHW (1'-0" o.c.)
1 /
8
x 3 /
16
" Pop Rivet (1'-0" o.c.)
Pro-Loc Z-Closure
Double Bead Tape Sealant
Rake
#10-12 x 1" PHW (1'-0" o.c.)
Cleat
1 /
8
x 3 /
16
" Pop Rivet (1'-0" o.c.)
#10-12 x 1" PHW (1'-0" o.c.)
Z-Closure
Tube Sealant
Pro-Loc Panel
Tube Sealant
