Pro-loc i,ii – Metal Sales Pro-Loc II Manual User Manual
Page 16
PPL-16
PRO-LOC I,II
© Metal Sales Manufacturing Corporation/ Subject to change without notice/ Effective Date 9/11
800.406.7387 (Corporate Office) • www.metalsales.us.com
e
ndwall
wiTh
r
egleT
f
lashing
d
eTail
P
eak
d
eTail
Pro-loC i,ii
3:12 SLOPE
MINIMUM
3:12 SLOPE
MINIMUM
1
/
8
x
3
/
16
" Pop Rivet (3 per panel)
Pro-Loc Z-Closure
#10-12 x 1" PHW (4 per panel)
Pitch Break
Tube Sealant
Fastener (by others)
Reglet Flashing
Moisture Barrier (by others)
Double Bead Tape Sealant
Tube Sealant
Double Bead Tape Sealant
1
/
8
x
3
/
16
" Pop Rivet (3 per panel)
Pro-Loc Z-Closure
#10-12 x 1" PHW (1'-0" o.c.)
Tube Sealant
Peak
Cleat
Pro-Loc Panel
#10-12 x 1" PHW (4 per panel)
Double Bead Tape Sealant
Moisture Barrier (by others)
Double Bead Tape Sealant
NOTE: Z-Closures must be field cut and bent to fit between
panel ribs (See Metal Sales Architectural Installation Manual).
NOTE: Z-Closures must be field cut and bent to fit between
panel ribs (See Metal Sales Architectural Installation Manual).
