PPL-17

PRO-LOC I,II

© Metal Sales Manufacturing Corporation/ Subject to change without notice/ Effective Date 9/11

800.406.7387 (Corporate Office) • www.metalsales.us.com

v

enTed

r

idge

d

eTail

Pro-loC i,ii

11" r

idge

/h

iP

d

eTail

3:12 SLOPE

MINIMUM

3:12 SLOPE

MINIMUM

Double Bead Tape Sealant

1

/

8

x

3

/

16

" Pop Rivet (1'-0" o.c.)

#10-12 x 1" PHW (1'-0" o.c.)

Vented Ridge Cover

Moisture Barrier (by others)

Tube Sealant

Pro-Loc Panel

Offset Cleat

Vent Drip

Vent Material

Double Bead Tape Sealant

1

/

8

x

3

/

16

" Pop Rivet (3 per panel)

Pro-Loc Z-Closure

#10-12 x 1" PHW (4 per panel)

Moisture Barrier (by others)

Pro-Loc Panel

Tube Sealant

11" Ridge/Hip Cover

Double Bead Tape Sealant

#14-13 x 1

5

/

8

" Dek Fast (1'-0" o.c.)

#10-12 x 1" PHW (4 per panel)

2"

NOTE: Z-Closures must be field cut and bent to fit between

panel ribs (See Metal Sales Architectural Installation Manual).

NOTE: Z-Closures must be field cut and bent to fit between

panel ribs (See Metal Sales Architectural Installation Manual).

2"
