16" Coverage 12" Coverage
16" Coverage 12" Coverage
1"
Striations
Striations
Minor Ribs
C
C
C
C
Minor Ribs
12"
12"
1"
1"
1"
16"
16"
1. Theoretical section properties have been calculated per AISI 2001 “Specification for the Design of Cold-formed Steel Structural Members with 2004
Supplement.” Ixx and Sxx are effective section properties for deflection and bending.
2. Allowable load is calculated in accordance with AISI 2001 specifications considering bending, shear, combined bending and shear, deflection, testing, fastener
pullout from 5/8" plywood, and pullover. Allowable load considers the worst case of 3 and 4 equal span conditions. Allowable load does not address web
crippling. Panel weight is not considered.
3. Deflection consideration is limited by a maximum deflection ratio of L/180 of span.
4. Allowable loads do not include a 1/3 stress increase in uplift.
SECTION PROPERTIES
ALLOWABLE UNIFORM LOADS psf
(3 or More Equal Spans)
Ga. Width
in
Yield
ksi
Weight
psf
Top In Compression Bottom In Compression Outward
Load
Ixx
in 4 /ft
Sxx
in 3 /ft
Ixx
in 4 /ft
Sxx
in 3 /ft 0'-6" 1'-0" 1'-3" 1'-6" 1'-9" 2'-0"
26 16" 80 0.90 0.0157 0.0168 0.0163 0.0175 86 71 64 56 46 42
24 16" 50 1.19 0.0210 0.0226 0.0210 0.0226 86 71 64 56 46 42
 Slope
 Substructure
 Coverage
 Length
 Fasteners
 Availability
GENERAL INFORMATION
The minimum recommended slope for the Image II roof
panel is 3:12.
Image II is designed to be utilized over a solid substrate.
To avoid panel distortion use a properly aligned and
uniform substructure.
NOTE: Image II roof panels are not recommended for use
over open structural framing.
Image II panels are available in a 1" seam height with a 12"
or 16" width coverage.
Minimum factory cut length is 5'-0". Maximum
recommended panel length is 30'-0". Longer panels
require additional consideration in packaging,
shipping, and erection. Please consult Metal Sales for
recommendations.
The fastener selection guide should be consulted for
choosing the proper fastener for specific applications.
Quantity and type of fastener must meet necessary loading
and code requirements.
NOTE: All panels are subject to surface distortion due to
improperly applied fasteners. Overdriven fasteners will
cause stress and induce oil canning across the face of the
panel at or near the point of attachment.
Finishes: Acrylic Coated Galvalume ® , MS Colorfast45 ® ,
or various Kynar 500 (PVDF) colors.
Gauge: 26 ga standard, 24 ga optional
ATTACHMENT DETAIL
FASTENING PATTERN
Image II Panel
#10-12x1" PH Woodscrew
