PIM-14
IMAGE II
© Metal Sales Manufacturing Corporation/ Subject to change without notice/ Effective Date 9/11
800.406.7387 (Corporate Office) • www.metalsales.us.com
r
aKe wiTh
Z-C
losUre
d
eTail
image ii r
aKewall wiTh
Z-C
losUre
(C
oUnTer
) d
eTail
Double Bead Tape Sealant
Image II Panel (field cut and bend)
Moisture Barrier (by others)
Rake
#8-18 x 3 /
4
" Truss Head Woodscrew (1'-0" o.c.)
Cleat
1 /
8
" x 3 /
16
" Pop-Rivet (1'-0" o.c.)
Z-Closure
Double Bead Tape Sealant
Image II Panel
Moisture Barrier (by others)
Rakewall
#8-18 x 3 /
4
" Truss Head Woodscrew (1'-0" o.c.)
1 /
8
" x 3 /
16
" Pop-Rivet (1'-0" o.c.)
Z-Closure
Counter Flashing
Fasteners (by others)
Tube Sealant
