Page 12
PIM-12
IMAGE II
© Metal Sales Manufacturing Corporation/ Subject to change without notice/ Effective Date 9/11
800.406.7387 (Corporate Office) • www.metalsales.us.com
s
loPe
C
hange
d
eTail
3"
image ii
v
alley
d
eTail
Double Bead Tape Sealant
Image II Panel
Moisture Barrier (by others)
Tube Sealant
Offset Cleat
#8-18 x
3
/
4
" Truss Head Woodscrew (1'-0" o.c.)
Image II Panel
Pitch Break
#8-18 x
3
/
4
" Truss Head Woodscrew (1'-0" o.c.)
Z-Closure
1
/
8
" x
3
/
16
" Pop-Rivet (3 per panel)
Double Bead Tape Sealant
Panel rib must be field notched and flat part of panel must be field
bent to accept offset cleat (see Architectural Manual).
Image II Panel
Moisture Barrier (by others)
Valley
Double Bead Tape Sealant
#9-15 x 1" Woodscrew (4 per panel)
3"
3:12 Slope
Minimum
3:12 Slope
Minimum
CAUTION
Additional screws
may be required for
high snow loading
and steep slopes.
Note: Z-Closures must be field cut and bent to fit between panel
ribs (see Architectural Manual).
